Spartan 3E Starter Board XC3S500E

Esta board integra una FPGA spartan de 500k compuertas, un procesador RISC de 32bits y una interfase DDR, ademas de puertos USB, ethernet, LCD, potenciometro, switchs, puertos seriales e interfase JTAG es totalmente compatible con Xilinx ISE^® tools .

Características

• (500K gates) XC3S500E FPGA
• Xilinx XCF04 Platform Flash for storing FPGA configurations
• Texas Instruments TPS75003 Triple-Supply Power Management IC
• JTAG & SPI Flash programming with parallel or USB JTAG cable
• Linear Technology Power Supplies
• 64MB Micron^® DDR SDRAM
• 16MB Numonyx StrataFlash™
• 2MB ST Microelectronics Serial Flash
• JTAG programming via on-board USB2 port
• Numerous additional configuration options
• SMSC LAN83C185 Ethernet PHY
• PS/2 keyboard
• RJ-45 Ethernet
• 16-pin header for optional LCD modules
• SMA connector for high-speed clock input
• Two DB9 RS-232 connectors
• 100-pin Hirose FX2 connector
• Three 6-pin Pmod ports
• DB15HD VGA

Ejemplo de aplicación
